Hello,
Last week I picked up a nice Kenwood KA-3500 40watt intergrated amplifier in pretty good shape.
Upon using it a bit more, I noticed a bit of distortion at high volume, more so in the left channel. I checked the DC offset at the speaker terminals, and the L channel said 100 mV, while the R was 25 mV. I understand this isn't so good for the L channel at least, but unfortunately this amp doesn't have any DC offset adjustments. Am I right in saying that to fix this I'd have to replace the output transistors?
--
On a related issue, in the service manual I found the section on BIAS adjustment, and I read online how it can affect the DC offset. So I hooked up my voltmeter to the test points, and I got 4 mV on the L, and 8 mV on the R. In the manual it says should be 40 mV.....(!). Is there something wrong here? I tried carefully adjusting them, but they only go to 30mV with the pots fully on, this doesn't seem right to me.
--
I compromised at 20 mV BIAS for both channels, and now the DC offset is 50 mV for L, and 5 mV for R, which is better, less than half what they were. I'm wondering, will I damage anything doing this, should I put them back to where they were?
--
The service manual is on site here.
Let me know if you want me to upload an english copy of the Owner's Manual, it has a better schematic in it all on one page, easier to read.
I've also included some pictures. They're not my actual unit, but mine is exactly the same, but less dusty.
--
Thanks for reading this. Many thanks in advance, and have a peaceful Palm Sunday! :taps2:
Bellarmine
Szevasztok,newezett HI-FI vel kűzdök,nincs kapcsolási rajzom,a végfok megy,de a TC 9213P toshiba Ic-nél megállt a tudomány.Nem találok róla adatlapot!Ha valaki tudna segíteni,kapcsolási rajzzal,vagy IC adatlappal,sokat segítene.Üdvözlettel:oivan
halihó, hoztak egy kenwood kdc-5090ry tipusú autórádiót, amely a kijelzőn bekapcsolás után WAITING 4 (gondolom) hibakódot ír ki. Az elért forrasztásokat átforrasztottam, majd egyszer bekapcsolt. Azóta akármit csinálok vele, hiába, csak a kijelzön lévő hibakód (?) van. Estleg ha tudtok valamit erről, megköszönném.
Sziasztok.
A fent említett erősítő csinálja a furcsa hangosítási hibát. Amikor halkan szól a bal oldali csatorna sokkal halkabb és magas hang hiányos. Amikor feljebb emelem a hangerőt akkor kis átütést hallani és megjelenik a magas hang is. Ezek után ha leveszem vagy visszaveszem a hangerőt minden rendesen működi azzal a kivétellel, hogy a bal csatorna még mindig halkabb mint a jobb. Na most, amikor a magas hangot ( Trabel potin ) feltekerem akkor a jobb csatorna is kiegyensúlyozottan szól, avagy egyforma hangerejük lesz.
Az erősítő nem az enyém, javításra hozták. Mivel fogalmam sincs ezt mi okozhatja, segítséget kérnék, mielőtt nekifekszem.
Előre is köszönöm a segítséget.
Az SM
Itt található
Laci
( javítva )
